What is SFP Transceiver, Types, Compatiblity, Applications, Standardization, Picture
What is SFP? The small form-factor pluggable (SFP) or Mini-GBIC is a compact, hot-pluggable transceiver used for bothtelecommunication and data communications applications. It interfaces a network device mother board (for a switch,router, fiber media converter or similar device) to a fiber optic or copper networking cable. It is a popular industry format jointly developed and supported by many network component vendors. SFP transceivers are designed to support SONET, Gigabit Ethernet, Fibre Channel, and other communications standards.
SFP Types
SFP transceivers are available with a variety of transmitter and receiver types, allowing users to select the appropriate transceiver for each link to provide the required optical reach over the available optical fiber type (e.g. multi-mode fiber or single-mode fiber). Optical SFP modules are commonly available in several different categories:
for multi-mode fiber, with black or beige extraction lever
SX - 850 nm, for a maximum of 550 m at 1.25 Gb/s (Gigabit Ethernet) or 150m at 4.25 Gb/s (Fibre Channel)
for single-mode fiber, with blue extraction lever
LX - 1310 nm, for distances up to 10 km
BX - 1490 nm/1310 nm, Single Fiber Bi-Directional Gigabit SFP Transceivers, paired as BS-U and BS-D for Uplink and Downlink respectively, also for distances up to 10 km
1550 nm 40 km (XD), 80 km (ZX), 120 km (EX or EZX)
CWDM and DWDM transceivers at various wavelengths achieving various maximum distances
for copper twisted pair cabling
1000base-T - these modules incorporate significant interface circuitry and can only be used for Gigabit Ethernet, as that is the interface they implement. They are not compatible with (or rather: do not have equivalents for) Fibre channel or SONET.
The way of SFP classification
Divided by rate :155M/622M/1.25G/2.125G/4.25G/8G/10G,155M and 1.25G market is used more, 10G technology is maturing, demand is to increase quickly.
Divided according to the wavelength : 850nm/1310nm/1550nm/1490nm/1530nm/1610nm.
The 850nm wavelength is SFP multimode, and the transmission distance is 2KM below.
1310/1550nm is SFP single-mode, and the transmission distance is longer than 2KM.
850nm/1310nm/1550nm price relatively cheaper than the other three.
The bare module is easy to confuse if they have no mark,the manufacturers will make the color of pull ring to distinguish generally, For example:
Black pull ring is multi-mode, the wavelength is 850nm;
Blue is the 1310nm module;
Yellow is the 1550nm module;
Purple is the 1490nm module and so on.
SFP, with its small and low-cost advantages to meet the equipment needs of high-density optical modules has become mainstream.
Transceiver | Data rate | Terms | Distance | Wavelengths |
155M/622M/ 1.25G/ 2.5G/3G/ 4.25G |
300m/2km/ | 850nm/1310nm/1550nm 1310nm/1490nm/1550nm 1270nm-1610nm ITU17~ITU61 | ||
6G/8.5G/10G | 220m/300m/ 2km/10km/ 20km/40km/ 60km/80km | 850nm/1310nm/1550nm 1270nm/1330nm 1270nm-1330nm ITU17~ITU61 |
SFP+
The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP. It supports data rates up to 10 Gbit/s. The SFP+ was first published on May 9, 2006, and version 4.1 published on July 6, 2009. SFP+ supports 8 Gbit/s Fibre Channel, 10 Gigabit Ethernet and Optical Transport Network standard OTU2. It is a popular industry format supported by many network component vendors.
Compatiblity
It is possible to design an SFP+ slot that can accept a standard SFP module.
Applications
SFP sockets are found in Ethernet switches and network interface cards. Storage interface cards, also called HBA's and Fibre Channel storage switches is another use of these type of modules, supporting different speeds like 2Gb, 4Gb and 10Gb. Because of their ability to provide a connection to different types of optical fiber, SFP provides such equipment with enhanced flexibility.
Standardization
The SFP transceiver is specified by a multi-source agreement (MSA) between competing manufacturers. The SFP was designed after the GBIC interface, and allows greater port density (number of transceivers per cm along the edge of a mother board) than the GBIC, which is why SFP is also known as mini-GBIC. The related Small Form Factor transceiver is similar in size to the SFP, but is soldered to the host board as a pin through-hole device, rather than plugged into an edge-card socket.[citation needed]
However, as a practical matter, some networking equipment manufacturers engage in vendor lock-in practices whereby they deliberately break compatibility with "generic" SFPs by adding a check in the device's firmware that will only enable the vendor's own modules.
Signals
The SFP transceiver contains a PCB that mates with the SFP electrical connector in the host system.
SFP pin-outPin | Function | Pin | Function |
20 | VeeT | 1 | VeeT |
19 | TD- | 2 | TxFault |
18 | TD+ | 3 | TxDisable |
17 | VeeT | 4 | MOD-DEF(2) |
16 | VccT | 5 | MOD-DEF(1) |
15 | VccR | 6 | MOD-DEF(0) |
14 | VeeR | 7 | RateSelect |
13 | RD+ | 8 | LOS |
12 | RD- | 9 | VeeR |
11 | VeeR | 10 | VeeR |
MOD-DEF 0,1,2 are the mode definition pins.
MOD-DEF 0 is grounded by the module to indicate that the module is present
MOD-DEF 1 is a clock SCL line for the I²C identification EEPROM
MOD-DEF 2 is a data SDA line for the I²C identification EEPROM
Mechanical dimensions
SFP dimensions are:
Height: 8.5 mm (0.33 inches)
Width: 13.4 mm (0.53 inches)
Depth: 56.5 mm (2.22 inches)
EEPROM information
The SFP MSA defines a 256-byte memory map in EEPROM describing the transceiver's capabilities, standard interfaces, manufacturer, and other information, which is accessible over I2C interface at the 8-bit address 1010000X (A0h).
Digital diagnostics monitoring
Modern optical SFP transceivers support digital diagnostics monitoring (DDM) functions according to the industry-standard SFF-8472. This feature is also known as digital optical monitoring (DOM). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.
The diagnostic monitoring controller is available as I²C device at address 1010001X (A2h).
Tag: SFP Transceiver
