10G BIDI SFP+ 40km Transceiver SPT-PB2733TG-L40D

Storage Temperature

Ts

-40

-

85

ºC

Storage Ambient Humidity

HA

5

-

95

%

Operating Relative Humidity

RH

-

-

85

%

Power Supply Voltage

VCC

-0.3

-

4

V

Signal Input Voltage

Vcc-0.3

-

Vcc+0.3

V

Case Operating Temperature

Tcase

-5

-

70

ºC

Without air flow

Power Supply Voltage

VCC

3.14

3.3

3.47

V

Power Supply Current

ICC

-

300

450

mA

Data Rate

BR

10.3125

Gbps

Transmission Distance

TD

-

40

km

Note (1)

Coupled fiber

Single mode fiber

ITU-T G.652

Transmitter

Average Launched Power

PO

-1

-

4

dBm

Average Launched Power(Laser Off)

Poff

-

-

-40

dBm

Note (1)

Center Wavelength Range

λC

1260

1270

1280

nm

Side mode suppression ratio

SMSR

30

-

-

dB

Spectrum Bandwidth(-20dB)

σ

-

-

1

nm

Extinction Ratio

ER

3.5

-

dB

Note (2)

Output Eye Mask

Compliant with FC_PI_4 REV 7.0

Note (2)

Receiver

Input Optical Wavelength

λIN

1320

1330

1340

nm

Receiver Sensitivity

Psen

-

-

-15

dBm

Note (3)

Input Saturation Power (Overload)

PSAT

0.5

-

-

dBm

Note (3)

LOS -Assert Power

PA

-30

-

-

dBm

LOS -Deassert Power

PD

-

-

-17

dBm

LOS -Hysteresis

PHys

0.5

-

5

dB

Total power supply current

Icc

-

300-

450

mA

Transmitter

Differential Data Input Voltage

VDT

180

-

700

mVp-p

Differential line input Impedance

RIN

85

100

115

Ohm

Transmitter Fault Output-High

VFaultH

2.4

-

Vcc

V

Transmitter Fault Output-Low

VFaultL

-0.3

-

0.8

V

Transmitter Disable Voltage- High

VDisH

2

-

Vcc+0.3

V

Transmitter Disable Voltage- low

VDisL

-0.3

-

0.8

V

Receiver

Differential Data Output Voltage

VDR

300

-

850

mVp-p

Differential line Output Impedance

ROUT

80

100

120

Ohm

Receiver LOS Pull up Resistor

RLOS

4.7

-

10

KOhm

Data Output Rise/Fall time

tr/tf

-

38

ps

LOS Output Voltage-High

VLOSH

2

-

Vcc

V

LOS Output Voltage-Low

VLOSL

-0.3

-

0.4

V

1

V_EET

Transmitter Ground (Common with Receiver Ground)

1

2

T_FAULT

Transmitter Fault.

2

3

T_DIS

Transmitter Disable. Laser output disabled on high or open.

3

4

SDA

2-wire Serial Interface Data Line

4

5

SCL

2-wire Serial Interface Clock Line

4

6

MOD_ABS

Module Absent. Grounded within the module

4

7

RS0

Rate Select 0

5

8

LOS

Loss of Signal indication. Logic 0 indicates normal operation.

6

9

RS1

No connection required

1

10

V_EER

Receiver Ground (Common with Transmitter Ground)

1

11

V_EER

Receiver Ground (Common with Transmitter Ground)

1

12

RD-

Receiver Inverted DATA out. AC Coupled

13

RD+

Receiver Non-inverted DATA out. AC Coupled

14

V_EER

Receiver Ground (Common with Transmitter Ground)

1

15

V_CCR

Receiver Power Supply

16

V_CCT

Transmitter Power Supply

17

V_EET

Transmitter Ground (Common with Receiver Ground)

1

18

TD+

Transmitter Non-Inverted DATA in. AC Coupled.

19

TD-

Transmitter Inverted DATA in. AC Coupled.

20

V_EET

Transmitter Ground (Common with Receiver Ground)

1

1.0

2010-09-01

Preliminary datasheet

2.0

2011-09-10

Update format and company’s logo
